6060 T5 Extrusions Grade - Aluminium

Range Enquiry

To enquire about our range or your specific requirements, please contact your local service centre.

Temper Types

The most common temper for 6060 aluminium is:

Properties

Chemical Composition

Chemical Element	% Present
Manganese (Mn)	0.00 - 0.10
Iron (Fe)	0.10 - 0.30
Magnesium (Mg)	0.35 - 0.60
Silicon (Si)	0.30 - 0.60
Copper (Cu)	0.00 - 0.10
Zinc (Zn)	0.00 - 0.15
Titanium (Ti)	0.00 - 0.10
Chromium (Cr)	0.00 - 0.05
Other (Each)	0.00 - 0.05
Others (Total)	0.00 - 0.15
Aluminium (Al)	Balance

Mechanical Properties

Mechanical Property	Value
Proof Stress	120 Min MPa
Tensile Strength	160 Min MPa
Elongation A50 mm	6 Min %
Hardness Brinell	60 HB
Elongation A	8 Min %

General Physical Properties

Physical Property	Value
Density	2.70 g/cm³
Melting Point	655 °C
Thermal Expansion	23.4 x 10^-6/K
Modulus of Elasticity	69.5 GPa
Thermal Conductivity	209 W/m.K
Electrical Resistivity	54 % IACS
Electrical Resistivity	0.032 x 10^-6 Ω .m

Applications

Architectural sections for windows, doors, curtain walls
Interior fittings, frame systems, lighting, ladders, railings, fences
Heat sink sections, electronic modules, electro motor housings
Flexible assembly systems, special machinery elements
Truck and trailer flooring, pneumatic installation, railway, inside applications
Irrigation, heating and cooling pipes
Furniture, office equipment

Characteristics

Very good corrosion resistance
Very good weldability
Good cold formability especially in temper T4
Suitable for anodising

Additional Information

Weldability

Process	Rating
Weldability - Gas	Good
Weldability - Arc	Very Good
Weldability - Resistance	Good
Brazability	Very Good

Process	Rating
Workability - Cold	Good
Machinability	Acceptable
Anodising	Very Good
