Plastics, PVCRecycled Foam PVC Sheet

Make a greener choice with recycled foam PVC sheets.

Manufactured with a recycled black core, a premium quality white surface is co-extruded from virgin PVC material ensuring a smooth, even layer for print and display, creating a better quality finish for all types of processing.

The high density surface of the sheet provides excellent resistance whilst the colour formulation of this surface layer has been developed specifically for digital processing to maximise colour reproduction and minimise the occurrence of UV yellowing resulting in a brighter whiter sheet with ‘green’ credentials.

Containing up to 80% recycled content, the white surfaces and black core of these PVC foam sheets provide endless creative design opportunities.

Talk to an expertDownload PDF

Range

Sheet SizeThicknesses
1220 x 24403.0mm & 5.0mm
1220 x 30503.0mm & 5.0mm
If you do not see what you are looking for, please contact your local service centre with your specific requirements.

Properties

PropertyValue
Physical Properties
Base PolymerPolyvinyl Chloride (PVC)
FormUnplasticised rigid foam PVC shhet
SmellColourless
Moisture Absorption (24hr @ 23OC)<0.25% by weight
Water SolubilityInsoluble
Oxygen Index48%
Mechanical Properties
Tensile Strength at Yield16MPa
Modulus of Elasticity0.85-0.9 MPa
Elongation at Break27-29%
Flexural Strength25-27 MPa
Impact Resistance (Charpy)15 kJ/m2
Average Sheet Hardness> 30 Shore D
Thermal Properties
Vicat Softening Temp73-76 °C
Thermal Expansion Coeff0.068 mm/m °C
Service Temp Range-20 to +60 °C
Thermal Conductivity K0.085 W/m °C
Thermal Decomposition Temp>200°C
Electrical Properties
Dielectric Strength100 kV/cm
Surface Resistance>1012 Ohm
Volume Resistivity4 x 1015 Ohm*cm
Dielectric Constant2.4 (for 1kHz)
Dielectric Dissipation Factor0.013 (for 1kHz)
Tracking Resistance600 CPI

Additional Information

Fabrication

Applications

The range offers superb screen printing and direct to substrate digital printing results, the product gives excellent effects when routered or engraved.

  • Shop outfitting, exhibition stands and displays
  • Signage and point of purchase/sale
  • Vinyl application and photo mounting
  • Screen printing
  • Direct digital printing

Characteristics

  • Recycled black core
  • Bright white surface
  • Consistently smooth and even
  • Quality digital and screen printing
  • Quality digital and screen printing
  • Environmentally sound
  • Light and cost-effective
  • Hard and resilient
  • Versatile
